BRS-36BAY-HSERVER, High-Spec Rackmount VMS Recording Server

BRS-36BAY-HSERVER, High-Spec Rackmount VMS Recording Server

BRS-HSERVERS is an enterprise-grade VMS recording server built for large-scale sites — logistics warehouses, manufacturing plants, shopping malls — that need to record hundreds of cameras from a single centralized system around the clock. Available in 2U or 4U rackmount chassis options, it fits into a server room or camera cabinet, and its 12 or 36 hot-swap drive bays let you scale capacity as a project grows. The Intel Xeon Silver 4410Y processor paired with 32GB DDR5 ECC memory delivers enough processing headroom to handle simultaneous live viewing across many channels while recording continues uninterrupted.

• Redundant 800W/1200W Gold-certified power supply: If one power supply fails on the warehouse or factory floor, the system keeps running without a recording gap.
• Battery-backed hardware RAID (RAID5 default, 0/1/1+0/5/6/50/60 supported): Data on the drives is protected during a sudden power loss, and a single drive failure won't cause footage loss — important for retail chains reviewing end-of-shift recordings.
• Hot-swap 12 or 36 drive bays, up to 350TB raw storage in the 36-bay model: Holds months of continuous archive from a high-resolution camera fleet, and drives can be swapped without shutting the system down.
• 2 x 10GbE RJ45 network ports plus a dedicated IPMI LAN: Camera traffic and management traffic run on separate lines; IT staff can remotely diagnose hardware issues via IPMI without a site visit.
• 2 x 240GB SATA OS drives running WinServer25: Separating the VMS operating system from the recording drives means an OS-level issue won't affect the recorded archive.
• 5-year Next Business Day warranty: Replacement parts arrive the next business day in case of a critical hardware failure — long-term operational assurance for site managers and plant operators.

This class of server is chosen when logistics centers need to record close to a hundred cameras covering loading docks from one point, when production lines need to archive high-bitrate quality-control footage for months, or when malls and site management companies want to consolidate multi-building camera infrastructure into a single server. The 1500Mbps throughput rating keeps bandwidth from becoming a bottleneck in multi-channel 4K recording scenarios. With an operating temperature range of 5-35°C, the server is designed for climate-controlled server rooms — it is not suited for outdoor or non-air-conditioned warehouse environments.

Securiturk's engineering team can help you select the right 2U/4U chassis, drive count, and RAID configuration for your project scale. Send us your camera inventory and retention requirements, and we'll prepare a quote for the right BRS-HSERVERS configuration.
