SBP-180CMS, Ball Head Ceiling Mount Base

SBP-180CMS, Ball Head Ceiling Mount Base

The SBP-180CMS is an aluminum ball head ceiling mount base used together with Hanwha Vision Wisenet camera mount products. It is not a camera itself but an interface bracket that secures PTZ or box-type cameras to a ceiling in warehouses, retail stores, or office spaces. Its TR30 screw size and 19.1 mm (3/4", M25) conduit hole allow direct connection during installation without needing an extra adapter.

• Aluminum housing: Lightweight yet sturdy, so it adds no extra load when mounting at height.
• RAL9003 white finish: Blends in with white suspended ceilings in offices, retail corridors, and shopping malls, keeping the mount point discreet.
• TR30 screw connection: A standard screw size that connects directly to compatible Wisenet mount accessories without additional adapters.
• 19.1 mm (3/4", M25) conduit hole: Lets power and data cables pass neatly through the ceiling, avoiding visible cable clutter.
• ø180x86.5 mm size, 970 g weight: The base sits on a wide ceiling surface for a solid mount while remaining light enough for a single installer to handle.

SBP-180CMS is compatible with SBP-150CMP, SBP-300CMP, SBP-900CMP, SBP-C15P, and SBP-C15H mount accessories, completing ceiling installations without compromising system integrity. It suits warehouse entry points, production line cameras, and shared area cameras managed by site administrations wherever ceiling mounting is required.

If you're unsure which camera and mount accessory combination fits your project, contact the Securiturk project team for a compatibility check and quote.
